This webinar will show you how to develop and test battery management systems (BMS).

As the BMS closely monitors and protects a battery during its lifetime, it is vital to thoroughly test its components, such as battery and cell management units (BMU & CMU), firmware, and cell balancing performance for all operating conditions and fault scenarios.

Simulink provides a single environment for model-based design and testing. It enables developing the BMS and modeling the batteries’ behavior. Speedgoat cell emulation hardware can mimic the behavior of hundreds of battery cells individually, including their electrical and thermal dynamics. The unified solution allows hardware-in-the-loop-based validation of your BMS.

Typical applications include battery electric vehicles (BEV), grid energy storage, consumer electronics, electric ships, and electric aircraft.

The webinar features the following highlights:

  • Modeling of a 48V battery system, including its thermal behavior using Simulink® and Simscape Battery™ and running it on cell emulation hardware
  • Model-based design of a battery management system (BMS), including its battery (BMU) and cell management units (CMU)
  • Validating BMS functions, such as fault detection, cell balancing, and state-of-charge estimation
  • Implementation of bus and signal-level communication with an NXP BMS controller
  • Test automation and requirements-based testing using Simulink Test.
  • Interactive testing with MATLAB using custom MATLAB apps.

Hardware-in-the-Loop Testing of Battery Management Systems

Webinar session including interactive Q&A: 60 minutes


Date and Time Registration Link
24 April 2024, 02:00 EDT / 08:00 CET / 15:00 CST

Register for free

24 April 2024, 07:00 EDT / 13:00 CET / 20:00 CST

Register for free

24 April 2024, 11:00 EDT / 17:00 CET / 00:00 CST

Register for free


Christoph Hahn

Dr.-Ing. Christoph Hahn

Head of Technical Marketing, Speedgoat


Jatin Anand

Application Engineer, Speedgoat


Dr. Danielle Chu

Senior Product Marketing Manager - Simscape Battery, MathWorks
