Register now for the upcoming webinar

Prototype Converter Control Designs and Test Converters & Their Controllers

Wednesday, 28 May 2025

Join our webinar and learn how to leverage an end-to-end power electronics development and testing workflow – from early design to final implementation.

This webinar will guide you step-by-step through a testing workflow covering the deployment of control designs on scalable and powerful prototype controllers and off-the-shelf converters – so you can conduct testing on both signal and power level.

You will also gain insight into FPGA-based hardware-in-the-loop (HIL) testing of your power electronics controllers at nanosecond resolutions in deterministic real-time and power hardware-in-the-loop (Power HIL) testing to thoroughly validate connected and fully powered electrical equipment.

Discover how to:

    • ✅ Prototype field-oriented control (FOC) controls for a two-level, three-phase inverter and a permanent-magnet synchronous motor (PMSM) electric motor.
    • ✅ Test control designs for a 440-kW electric drive at rated power levels before the drive hardware is available
    • ✅ Perform controller hardware-in-the-loop (HIL) testing for various power converter topologies, including NPC (DC/AC), DAB (DC/DC), and PFC (AC/DC).
    • ✅ Leverage Speedgoat test systems to emulate motors and battery packs for safely and quickly testing traction inverters at up to hundreds of kilowatts

With Simulink® and Speedgoat test systems, you can:

    • ➡️ Frontload testing and reuse the same electrical system models from initial control prototyping to final verification-and-validation activities.
    • ➡️ Kickstart innovation and testing with turnkey models of electrical systems, including switching dynamics, power sources, and loads.
    • ➡️ Automate testing and manage test requirements end-to-end for continuous control function validation.

Demo_Image_Power_Electronics

Learn how to accelerate your innovation pace by frontloading testing at both signal and power levels, leveraging ready-made and hardware-proven Simulink® models, and safely expanding test coverage over operating and fault conditions. 

Excited? Register for the webinar.

Rohan Dhuri

Rohan Dhuri
Technical Marketing Engineer

 Manuel Fedou

Manuel Fedou
Senior Application Engineer Electrification

Join us live for an interactive 60-minute webinar, including a Q&A session! Select your preferred time slot now:

Can't make it live? No worries—register now, and we'll send you a link to watch the recording on-demand.



Register for webinar
