ARINC 825

Simulink® Driver Blocks for ARINC 825 Communication

The turnkey ARINC 825 blockset empowers you to send and receive scheduled CAN messages without having to design your own CAN structure for avionic applications. You will also benefit from a hardware timestamp which enables you to achieve high resolution and an accuracy of ±1 bit time, with very low jitter. Additionally, all channels can have their own scheduling table with an individual minor time frame period.

This blockset is ideal for closed-loop controls, hardware-in-the-loop simulations and restbus simulation using MATLAB® and Simulink®. The ARINC 825 blockset is fully compatible with the Simulink® Real-Time™ workflow. The extensive Simulink® Real-Time™ driver blockset offers comprehensive functionality.

Key Features

  • Minor time frame scheduling with timer resolution < 1 µs
  • Unlimited number of minor time frames
  • Minor time frame period ≥ 0.5 ms
  • 64-bit timestamp

Hardware Selection Guide

I/O Module Number of Ports Machine Compatibility
IO602 (requires run-time license) 4 Performance, Mobile and Baseline real-time target machines
IO691 (requires run-time license) 2 Unit and Baseline real-time target machines






I/O Access
Communication standard  ARINC 825-3 and ARINC 825-4
Communication layer CAN
Message frame format CAN 2.0B messages (29-bit identifier)
Item ID Product Name Components
2X602* ARINC 825 Run-Time License
  • 1 x ARINC 825 perpetual Run-Time License with 1-year software maintenance included (license bound to system)
  • Driver block library for Simulink® Real-Time™
  • Comprehensive documentation and Simulink® example models
2A602X IO602
  • 1 x IO602 CAN I/O module
  • 1 x 25-pin D-sub to 4x 9-pin D-sub splitter cable
  • 2 x CAN Loopback Test Cables with termination resistor (120 Ω)
  • Driver block library for Simulink® Real-Time™
  • Comprehensive documentation and Simulink® example models
  • Installation into the real-time target machine

2B602X



IO602-T

  • 1 x IO602-T CAN I/O module with Extended Temperature Range
  • 1 x 25-pin D-sub to 4x 9-pin D-sub splitter cable
  • 2 x CAN Loopback Test Cables with termination resistor (120 Ω)
  • Comprehensive documentation and Simulink® example models
  • Installation into the real-time target machine

2A691X

IO691

  • 1x IO691 CAN I/O module
  • 1x CAN Loopback Test Cable with termination resistor (120 Ω )
  • Driver block library for Simulink® Real-Time™
  • Comprehensive documentation and Simulink® example models
  • Installation into the real-time target machine

2C691X

IO691-T

  • 1x IO691-T CAN I/O module with extended temperature range
  • 1x CAN Loopback Test Cable with termination resistor (120 Ω )
  • Driver block library for Simulink® Real-Time™
  • Comprehensive documentation and Simulink® example models
  • Installation into the real-time target machine

* Please replace the X with the code number of the specific target machine for the I/O module installation:

5 = Mobile real-time target machine

6 = Performance real-time target machine

7 = Unit real-time target machine

8 = Baseline real-time target machine



Pricing information
We do not publish pricing information on our website. Upon request by e-mail or phone, we can provide a complete price list covering our entire product portfolio in various currencies. We recommend that you contact us to discuss your specific needs. We can then quickly provide you with a tailored quotation including technical and pricing information.


io191

Included in the Delivery

  • ARINC 825 run-time license
  • Simulink® driver blocks
  • Test models
  • Comprehensive documentation
  • Not included: IO602 or IO691 I/O module (required for use with the ARINC 825 blockset)

Common Applications
