In-Vehicle Installation with Optional Lab/Desk Installation
Each Mobile real-time target machine is pre-configured for in-vehicle installation. In addition, it can also be used for desk/lab placement. Optional mounting plate is provided to mechanically fix the real-time target machine to a particular location. The mounting plate includes a set of clamps for mounting to a pair of DIN-rails (item ID 105362).
By default, the Mobile real-time target machine is equipped with a dual core CPU with a 2.4 GHz clock rate. It can run applications with sample rates in the range of tens of kHz. To run applications with multiple sample rates, enabling deployment of larger and complex Simulink models, the 2.7 GHz six core option is recommended.
For applications or application components requiring sample rates up to the MHz range, you can choose from a selection of Simulink programmable FPGAs, also including lowest latency analog and digital I/O connectivity.
Within Simulink, you can define which application components you want to execute on the CPU, and which ones on one or multiple programmable FPGAs, at different sample rates.
High Speed Data Logging
Real-time testing frequently requires logging large amounts of data for an extended period of time, analyzed after real-time execution such as with Simulink Simulation Data Inspector, you can hence choose SSDs with up to 2 TB of size for data logging.
